Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter

Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter

Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter
Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter

Large Image :  Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter Get Best Price

Product Details:

Place of Origin: Hebei China
Brand Name: MLG
Certification: CE
Model Number: MLG-3000

Payment & Shipping Terms:

Minimum Order Quantity: One set
Packaging Details: Hexagonal Wire Mesh Machine Plastic Film Packing, Other Spare Parts Contain In The Small Box Together With The Main Machine.
Delivery Time: 30 days after receiving deposit or L/C.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 4--5 sets per month
Detailed Product Description
Product Name: Haxagonal Wire Mesh Weaving Machine Material: Iron
Color: Yellow Name: Gabion Wire Mesh Machine
Mesh Size: 1/2 Inch 1 Inch 2 Inches 3 Inches 4 Inches Width Of Mesh: Max 3300mm
High Light:

hexagonal wire mesh machine

,

wire mesh weaving machine

Light type hexagonal wire mesh machine:





Our factory is specilized in producing kinds of wire mesh machine, our machine export to many countries, and because of our high quality and good after-sale service, we have many old customers.

Product :

Our straight and reverse twisted hexagonal wire mesh machine

1. Based on the principle of straight and reverse twisted method , it is unnecessary to make wire spring form to work, so the production increased a lot



2.. include main machine and auxiliary machine: spool winding machine.



3. The machine have adopted automatic stop system, when meet broken wires or broken mesh it will stop automatically



4. Concentrate lubricating system, simply operate and for machine maintain



5.. The machine have a electronic counter, the machine will stop when it reach the length of you set up.



6. Within the scope of mesh width, you can choose mesh width freely ,such as if the mesh size is 2.5m,you can produce 2 mesh size 1m at the same time.



Main machine



1. Normal twisted type



Types Width(mm) Mesh (inch) Diameter (mm) Number of twist Weight (T)

Power

KW

MLG15 1200--2200 1/2 ≤0.6 3-5 2.5 2.2
MLG20 1200--2200 3/4 ≤0.8 3-5 2.5 2.2
MLG18 1200--2200 5/8 ≤0.7 3-5 2.5 2.2
MLG25 1200--2200 1 ≤0.9 3-5 2.5 3.0
MLG40 1200--2200 1.5 ≤1.0 3-5 2.5 3.0
MLG50 1200--2200 2 ≤1.6 3-5 2.5 3.0
MLG60 1200--2200 2.5 ≤1.8 3-5 2.5

3.0







Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 0

Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 1



2.Positive and Negative Hexagonal Wire Netting Machine



Model Mesh size  Max net width (mm) max wire diameter(mm) theoretical productivity dimension(mm) weight(T)
single double   mesh/min m2/h
ZJ1/2 1/2inch 2490 1200 0.75 38 50 4500X2200X1450 4.6
ZJ3/4 3/4inch 2490 1200 1.0 38 62 4500X2200X1450 4.6
ZJ1 1inch 2490 1200 1.2 38 66 4500X2200X1450 4.6
ZJ1.2 1/2inches 2490 1200 1.2 38 99 4500X2200X1450 4.6
ZJ1.5 1inch 2490 1200 1.4 38 131 4500X2200X1450 4.6
ZJ2 2cines 2490 1200 1.6 38 169 4500X2200X1450 4.6
ZJ3 3inches 2490 1200 1.8 38 169 4500X2200X1450 4.6



Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 2



Accessoroes



1 Pyaoffd wire stand



Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 3



2 Spring machine



Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 4



Professional Light Type Hexagonal Wire Netting Machine With Electronic Counter 5
